Malossi 3111140 Aluminium Cylinder Kit Ø 65 mm H2O for Piaggio

Malossi 3111140 Aluminium Cylinder Kit Ø 65 mm H2O for Piaggio

€493,01 EUR
€493,01 EUR
Aanbieding Uitverkocht
Inclusief btw. Verzendkosten worden berekend bij de checkout.

This high-performance aluminium cylinder kit is engineered to deliver maximum power and reliability for water-cooled 125cc to 180cc two-stroke maxi scooters. Featuring a 65 mm bore and a 6-transfer port timing system, it provides a substantial displacement increase up to 172.5cc for optimized thermal efficiency and racing performance.

Crafted specifically for closed-course competition use, the package includes premium replacement components such as a matching cylinder head, specialized carbon fiber reed petals, piston rings, and full gasket assemblies to ensure a precise, sealed fitment.

Key Features

Brand Malossi
Manufacturer Part Number 3111140
Product Type Cylinder Kit
Bore 65 mm
Stroke 52 mm
Displacement 172.5 cc
Cooling System Liquid Cooled (H2O)
Timing System 6 Transfer Ports
Cylinder Material Aluminium
Engine Type 2-Stroke
Product Weight 3.2 kg

Highlights

  • High-grade aluminium cylinder with liquid cooling (H2O) design
  • Expanded 65 mm bore delivering 172.5cc displacement
  • Optimized 6-transfer port layout for peak two-stroke power delivery
  • Compatible with liquid-cooled Gilera, Italjet, and Piaggio 125-180cc platforms

Sizing & fit

Designed for 2-stroke liquid-cooled Piaggio engine cases. Compatible with Gilera Runner FX 125 / FXR-SP 180, Italjet Dragster 125 / 180, and Piaggio Hexagon 125 / 150 / LX 125 / LXT 180.

Compatibility

Manufacturer Model
GILERA GILERA RUNNER FX 125 2T LC
GILERA GILERA RUNNER FXR - SP 180 2T LC
ITALJET ITALJET DRAGSTER 125 2T LC
ITALJET ITALJET DRAGSTER 180 2T LC
PIAGGIO PIAGGIO HEXAGON LX 125 2T LC
PIAGGIO PIAGGIO HEXAGON LXT 180 2T LC
PIAGGIO PIAGGIO HEXAGON 125 2T LC
PIAGGIO PIAGGIO HEXAGON 150 2T LC

What's included

SKU Name
118337 Complete cylinder gasket set Ø 65
195113e 2 studs M 8x45 for exhasut system
236730 Pin Ø 16x10x55 for piston
277054.c0 6 VL11 and original valve carbon fibre petals with thickness 0,30/0,35/0,40
3111139 Aluminium cylinder Ø 65 H2O
348512 Piston 2T Ø 65 with pin Ø 16 and 2 semi-trapezoidal rings size 0
348512.a0 Piston 2T Ø 65 with pin Ø 16 and 2 semi-trapezoidal rings size A
348512.b0 Piston 2T Ø 65 with pin Ø 16 and 2 semi-trapezoidal rings size B
348512.c0 Piston 2T Ø 65 with pin Ø 16 and 2 semi-trapezoidal rings size C
348512.d0 Piston 2T Ø 65 with pin Ø 16 and 2 semi-trapezoidal rings size D
354554 2 piston rings Ø 65x1.2 semi-trapezoidal
364452 Pin clip Ø 16x1.2 C-shaped
3819718 Cylinder head Ø 65 aluminium H2O

Downloads

Frequently asked questions

What is the displacement of this cylinder kit?

This cylinder kit features a 65 mm bore and a 52 mm stroke, resulting in a displacement of 172.5cc.

Which scooter models are compatible with this cylinder kit?

It is compatible with liquid-cooled 2-stroke models including the Gilera Runner FX 125, Gilera Runner FXR-SP 180, Italjet Dragster 125/180, and Piaggio Hexagon 125/150/180 (LX/LXT).

What type of cooling system does the cylinder require?

This aluminium cylinder kit is designed specifically for liquid-cooled (H2O) engine setups.

Is this cylinder kit street legal?

No, this product is designed and reserved exclusively for racing competitions in authorized locations.
